Buy 2025 SANY SH500 Hydraulic Grab

The SANY SH500 Hydraulic Grab is engineered for heavy-duty material handling and excavation tasks. Its powerful hydraulic system provides excellent lifting and gripping strength for challenging environments. Built with durable components and precision controls, it ensures smooth, efficient operation. Ideal for mining, construction, and port loading, this attachment delivers consistent reliability. Designed for long service life, it enhances overall productivity and operational efficiency.

Features-

• Powerful: The working device has large weight and maximum impact power, and can be deployed in strongly weathered rock strata within 10MPa.
• Fast: The opening and closing time of the bucket is only 9 seconds, and the efficiency of soil catching, slag collecting and unloading is higher. The winch adopts synchronous confluence technology with the fastest speed.
• Straight: The dynamic real-time detection technology of gyroscope is adopted to adjust the deviation of the gantry push plate in real time, and the perpendicularity of the groove can reach 1‰.
• Deep: The construction depth is 80 meters, covering more than 90% of underground support projects, and the quality of grooves deeper than 60 meters is higher.
• Economical: The main winch adopts single-layer large drum, and the wire rope has longer service life.
• Convenient: It is equipped with electric centralized lubrication system and hydraulic quick-change joint to improve the convenience of disassembly, installation and maintenance.
• Intelligent: Professional operating system with real-time display of drilling situation.
• Stable: Professional large gauge chassis reduces rapid impact and shake and improves construction safety.

Parameters–

• Base Engine: ISUZU 6UZ1
• Engine Power: 257/2000kW/rpm
• Emission Regulation: China Stage III
• Groove Width: 600-1200mm
• Groove Depth: 80m
• Overall Height: 17435mm
• Operating Weight: 100T
• Transport Width: 3500mm
• Transport Height: 3720mm
• Max. Closing Force: 165T
• Weight: 15-25T
• Open & Close Bucket Time: 10/10S
• Lifting Capacity: 2*270kN
• Max. Line Speed: 80m/min
• Wire Rope Diameter: 32mm
